Sticker Paper Cutting Machine
Description
Technical Parameters
Product introduction
A sticker paper cutting machine is an automated device that precisely cuts flat materials according to designed patterns.
Product advantages
High Efficiency: Capable of cutting up to 10,000 pieces per hour, ensuring stable production capacity.
Large Die-Cutting Area: A maximum die-cutting space of 450×450mm accommodates stickers of various sizes.
Fully Automatic Lubrication: Automatic intermittent oil supply reduces wear and extends equipment life.
Multi-Mold Applicability: Supports various cutting molds such as wood molds, rubber molds, and anti-corrosion molds.
Intelligent Control: The CNC system supports batch program saving, improving the efficiency of repetitive processing.
Easy Operation and Maintenance: Removable panels and modular components facilitate daily maintenance.
Product applications
Label processing plants use this product for mass sticker production.
Packaging design companies use it for sample or small-batch cutting.
The advertising industry uses it for personalized sticker cutting.
Product customization
Feed width: 460/500/600mm
Die-cutting area: 450×450/500×500/600×600mm
Operating speed: 10000/12000/15000PCS/h
Upper template size: 460×460/500×500mm
Air source specifications: 0.5-0.7/0.6-0.8/0.7-0.9MPa
FAQ
Q: What is the maximum size?
A: 450 × 450 mm
Q: Does it have a lamination function?
A: Yes, it has a lamination function.
Q: Can it roll or slice materials?
A: Yes, it can roll and slice materials.
Hot Tags: sticker paper cutting machine, China sticker paper cutting machine manufacturers, suppliers, factory, die cutting packaging, custom die cutter press, automatic die cutter press, die cutting liner, die cutting design, die cutter shafts
|
Name |
unit |
sticker paper cutting machine |
|
Feeding width |
mm |
460 |
|
Maximum die cutting area |
mm |
450(L)*450(W) |
|
Maximum operating speed |
PCS/h |
12000 |
|
Rated running speed |
PCS/h |
10000 |
|
Mold base stroke |
mm |
27 |
|
Stroke adjustment |
mm |
0-10 |
|
Lower template size |
mm |
460(L)*460(W) |
|
Upper template size (thick) |
mm |
460(L)*460(W) |
|
Dimensions |
mm |
2250(L)*1700(W)*1880(H) |
|
Machine net weight |
kg |
2900 |
|
Total power |
kw |
AC380V 8.0KW |
|
Air source specifications |
|
0.5-0.7Mpax 1L/Min |
|
Lubrication method |
|
Automatic gap type oil supply |
|
Applicable cutter |
|
Wood mold, rubber mold, corrosion mold, carving mold, hardware mold |
