Gasket Die Cutting Machines
Description
Technical Parameters
Product introduction
A gasket die-cutting machine is industrial equipment used to precisely cut thin materials into specific shapes.
Product advantages
High-Speed Stability: Rated speed of 12,000 PCS/h ensures continuous efficient production.
Precise Cutting: Die-cutting accuracy of ±0.05mm guarantees uniform piece dimensions.
Multi-Die Compatibility: Supports wood, rubber, metal, and QDC dies for cutting.
Automatic Lubrication: Gap-type oil supply system reduces wear and extends machine life.
Product applications
Electronic Gaskets: Suitable for manufacturing sealing and cushioning gaskets in electronics.
Automotive Parts: Produces brake pads, sealing gaskets, and other precise auto components.
Mechanical Industry: Used to manufacture intermediate gaskets or spacer sheets for machinery.
Home Appliances: Cuts gaskets for air conditioners, refrigerators, and washing machines.
Protective Materials: Suitable for cutting corrosion-resistant and shock-proof materials.
Product customization
Feeding Width: 355/400/450 mm
Die-Cutting Area: 350×350 / 400×400 / 450×450 mm
Compatible Cutting Dies: Wood/Rubber/Metal/QDC
Stroke Adjustment: 31/35/40 mm
Air Source Specification: 0.5/0.6/0.7 MPa
FAQ
Q: Does the device have a hole punch function?
A: It can be optionally installed.
Q: How many people are needed to operate the equipment?
A: Only one person is required.
Q: When can I get the price?
A: We usually provide a quotation within 8 hours after receiving your inquiry.
Hot Tags: gasket die cutting machines, China gasket die cutting machines manufacturers, suppliers, factory, die cutting foam, die cutting sample, high speed die cutter press, die cutting machine, die cutter system, die cutter calibration
|
name |
unit |
Gasket Die Cutting Machines |
|
Feeding width |
mm |
355 |
|
Maximum die cutting area |
mm |
350(L)*350(W) |
|
Maximum operating speed |
PCS/h |
18000 |
|
Rated running speed |
PCS/h |
12000 |
|
Mold base stroke |
mm |
26 |
|
Stroke adjustment |
mm |
31 |
|
Lower template size |
mm |
350(L)*350(W) |
|
Upper template size (thick) |
mm |
350(L)*350(W) |
|
Dimensions |
mm |
1355(L)*1420(W)*1380(H) |
|
Machine net weight |
kg |
1800 |
|
Total power |
kw |
AC380V 4.5KW |
|
Air source specifications |
|
0.5-0.7Mpa 1L/Min |
|
Lubrication method |
|
Automatic gap type oil supply |
|
Applicable cutter |
|
Wood mold, rubber mold, corrosion mold, carving mold, hardware mold, QDC mold |
